Collaborative palletizers specialize in lower case weights and feed rates while offering the smallest installation footprint requirement to bring automation into your facility. Fencing and hard guarding is not required as stack heights do not exceed the OSHA 60” threshold. Your team is protected by area safety scanners that throttle robot arm speed once penetrated. Lead time 8 weeks.
+Sealed RSCs (corrugated cases)
+Cases up to 40lbs
+Case dimensions up to 24” x 16” x 15”
+Feed rate up to 6.5 cycles/min
+1 in-1out or 1 in-2 out configurations available
+Stack height up to 60”
+Installation footprint 9’-6” x 10’ x 8’
This Collaborative palletizer provides increased arm reach and can stack master cases up to 70” high on a pallet. Safety fencing protects your team working on the line, while area scanners control the entrance to the pallet zones - triggering when breached without a full pallet waiting to be extracted. Lead time 10 weeks.
+Sealed RSCs (corrugated cases)
+Cases up to 40lbs
+Case dimensions up to 24” x 16” x 15”
+Feed rate up to 6.5 cycles/min
+1 in-2 out configuration
+Stack height up to 70”
+Installation footprint 10’ x 11’ x 8’
Compact industrial palletizers provide the best payload-to-space option, handling heavier case weights and faster feed speeds, while demanding the smallest installation area. The increased capability and speed comes with additional safety features for your team including safety fencing, entry safety scanners, and robot zone light curtains. Lead time 10 weeks.
+Sealed RSCs (corrugated cases), open top cases
+Cases up to 50lbs
+Case dimensions up to 24” x 16” x 15”
+Feed rate up to 10 cycles/min
+1 in-1 out and 1 in-2 out configurations available
+Stack height up to 82”
+Installation footprint 10’-6” x 13’-6” x 10’-6”
Capable of handling a wide range of master packing types, Industrial palletizers provide the greatest robot arm reach, handle the heaviest cases, and provide the highest stack heights. Safety fencing, entry area scanners, and robot zone light curtains come standard on every unit. Lead time 10 weeks.
+Sealed RSCs (corrugated cases), open top cases, bags
+Cases up to 60lbs
+Case dimensions up to 24” x 16” x 15”
+Feed rate up to 10 cycles/min
+1 in-1 out and 1 in-2 out configurations available
+Stack height up to 100”
+Installation footprint 14’-6” x 10’ x 11’-6”
Cartesian palletizers can handle heavy cases and pick multiple cases at once to form pallet layers more quickly, while requiring a very small installation footprint. Lead time 10 weeks.
+Sealed RSCs (corrugated cases)
+Cases up to 70lbs
+Case dimensions up to 24” x 16” x 15”
+Feed rate up to 8 cycles/min
+1 in-1 out configuration
+Stack height up to 96”
+Installation footprint 8’-6” x 7’x6” x 10’
Formic Full Service Palletizer Rentals provide the expert support required to instantly increase productivity, quality, and safety in your facility while ensuring ongoing operational success.
No large up front investment or long term commitment required. Pay as you go for unlimited month-to-month use of the palletizers.
Ongoing operational success is ensured through on call tech support and 100% maintenance coverage, both preventative and corrective, all for one fixed rate
As your production needs change, your equipment can change with you while maintaining your same fixed price.
Humans are not meant for stacking heavy boxes all day, but robots are - they love 1st, 2nd, and 3rd shift equally. Eliminate workers comp claims from bending, lifting, and twisting injuries on your production line while overcoming your dependence on unreliable temp labor.
See how easy it can be to get started with automation.
If speed isn’t a requirement and you can afford to have your staff involved in the stacking process, collaborative robots permit ‘human-in-the-loop’ operations allowing staff to place sheets and load pallets.
Industrial robots allow for compact palletizing operations and require very little maintenance, helping you reliably stack product at high speeds and in tight spaces.
Mechanical pushers and overhead gantries arrange product in patterns to stack cases or bags.
